09-30-2025 Q&A: Toolpath Undercuts, Pendant File Issues, and Machine Settings
Sep 30, 2025Note: You must be a member of the Learn Your CNC Academy Community to watch this replay. Benefits include weekly Q&A Meetups, weekly project lessons, monthly CNC challenges, an active community of Vectric users, past replay lessons & project files, and so much more!
In this Q&A session, we explored common CNC workflow challenges including undercut ridges in 3D toolpaths, troubleshooting NextWave pendant file recognition issues, customizing toolpath start points, and solving design/vector problems for suspended shapes. We also covered strategies for laser toolpaths, fine detail carving issues, and adjusting machine acceleration for more accurate time estimates.
Key Tips Learned in this Q&A:
-
3D Toolpath Lip Fix: Undercuts or lips on one side of a bowl can result from raster stepovers not dividing evenly across a component. Increasing stepover percentage or using a larger boundary offset removes the ridge.
-
NextWave Pendant File Issues: File naming matters—avoid special characters, extra periods, or long filenames. Ensure USB drives are formatted FAT32 and under size limits (often <32GB). The 10.1 pendant is especially picky.
-
Toolpath Start Control: Change raster angles or use molding/two-rail sweep toolpaths to control where toolpaths begin and how thickness transitions are handled.
-
Suspended Shapes (like a crab in a box): Use ungrouping and trimming vectors to separate cutouts, then rejoin closed vectors for inside profile cuts. Consider two-sided cutting for clean results.
-
Time Estimate Accuracy: In Vectric, adjust machine acceleration and rapid rates under Machine Setup. Get specs from your CNC manufacturer or measure manually to improve prediction accuracy.
Questions Answered in this Q&A:
-
00:01:25 – Why does my bowl model show a ridge/undercut only on one side?
-
00:10:15 – How do you accurately select the edge of a 3D component in 2D view?
-
00:13:31 – Why aren’t my toolpaths showing on the NextWave 10.1 pendant (file transfer issue)?
-
00:23:38 – How do I change toolpath start points and vary thickness along slopes?
-
00:33:54 – How can I cut a crab shape suspended in a box?
-
00:42:43 – Why does my laser toolpath cut twice or darker than expected?
-
00:48:18 – Why won’t my fine detail bit cut (seems too high above material)?
-
00:51:52 – How do I get square corners with a two-rail sweep?
-
00:56:41 – How can I adjust machine settings in Vectric to make time estimates accurate?
Keywords:
cnc, vectric, toolpaths, nextwave, pendant issues, usb format, 3d modeling, raster angle, molding toolpath, two-rail sweep, laser toolpath, time estimates, machine acceleration, suspended shapes
