09-23-2025 Q&A: Rings in 3D Models, Leaf Tips with Aspire, and Two-Sided Cutting Alignment

Note: You must be a member of the Learn Your CNC Academy Community to watch this replay. Benefits include weekly Q&A Meetups, weekly project lessons, monthly CNC challenges, an active community of Vectric users, past replay lessons & project files, and so much more!

In this Q&A session, we explored common challenges in Vectric software, including working with combined 3D models, handling Aspire leaf modeling, and solving alignment problems with two-sided cutting. We also discussed component resolution, text layout strategies, and bit selection for STL projects. The session wrapped up with tips on tool deflection, alignment pins, and details about the upcoming Vectric User Group Meeting.

Key Tips Learned in this Q&A:

• Modeling Resolution: When working with 3D models, always set modeling resolution to Very High for cleaner details and smoother surfaces.

• Zero Plane Use: Avoid unnecessary zero planes in 3D projects, as they can cause the software to cut the entire model rather than specific areas.

• Text Layout in Design: Use visual spacing adjustments for improved readability; pay attention to negative space to avoid “gutters” in text alignment.

• Aspire Two-Rail Sweep: Use two-rail sweeps with different profile orientations to create more realistic leaf tips curving up or down.

• Two-Sided Cutting Alignment: Always use three alignment pins instead of two to prevent flipping errors. Place tabs on both sides in the same locations for stability.

Questions Answered in this Q&A:

• 00:03:09 – Why is my 3D ring project cutting everything instead of just the ring area?

• 00:19:09 – How can I make some leaf tips curve upward and others downward in Aspire?

• 00:30:59 – How to adjust bowl design, measure bottom thickness, and fix component sizing inconsistencies?

• 00:51:57 – How to properly align and tab a two-sided cut when bit length isn’t deep enough?

Keywords:

vectric, aspire, vcarve, cnc, 3d modeling, zero plane, modeling resolution, two rail sweep, text layout, bowl design, component sizing, two-sided cutting, alignment pins, tabs, stl files, vectric user group meeting
